ALT-C Round Tube Labeling Machine
ALT-C Round Tube Labeling Machine

ALT-C Round Tube Labeling Machine

Model NO.
ALT-C
Quantity:

Application
The automatic tube labeling machine is the ideal solution for pharmaceutical, chemical, food, cultural goods and other industries. The tube labeling machine takes care of every step, from lining up bottles to printing, tearing, affixing and sealing labels. The tube labeling machine can ensures your production line grows in efficiency and provides an end result that is polished and beautifully professional.

The tube labeling machine can print the date, batch and other crucial production icnformation within 3 lines of text with up to 12 characters per line. With some adjustments, the tube labeling machine can apply labels to flat, round, square and irregularly shaped bottles, depending on your unique needs.



Technical parameters

Power supply

AC220V 50/60HZ

Power

0.9KW

Labeling speed

0-300 tube/min (According to the bottle size and label size)

Labeling Accuracy

±0.5mm(Except the error of the labeled object and labels)

Tube diameter

20-120mm

Label size

H20-30mm L25-100mm

Temperature control

40~100℃±3℃

Max.Label Roll size

Outer dia.380mm, Inner dia.76mm

Weight

100KG

Overall size

1600x600x1500mm
