Automatic Slitting And Drying Machine
Automatic Slitting And Drying Machine
Automatic Slitting And Drying Machine

Automatic Slitting And Drying Machine

Model NO.
Automatic Slitting And Drying Machine
Quantity:

The Oral film slitting machine used for an intermediate process equipment, works on film peeling from mylar carrier, film drying to keep uniform, slitting process and rewinding process, that ensures its proper adaption to next packing process.The Oral film slitting machine new designed laser printing function. The Oral film slitting machine slitting funtion can equipp on the making machine. One Oral film slitting machine slitting funtion can support three units packing machine.


Technical parameters

Project

Parameter

Production Capacity

Standard 0.002m-5m/min

Finished Film Width

110-190 mm (Standard 380mm )

Raw material width

≤380mm

Total power

Three-phase five lines 220V 50/60Hz 1.5Kw

Air filter efficiency

99.95%

Air pump volume flow

≥0.40 m3/min

Packing material

Slitting composite film thickness (usually) 0.12mm

Overall dimensions ( L*W*H )

1930*1400*1950mm

Dividing material specifications

Roll type packing material

Material Roll outer diameter

Thickness

0.10-0.12

Roll inner diameter

φ76-78mm

Material Roll outer diameter

φ350mm
