RXH Series Hot Air Cycle Oven
RXH Series Hot Air Cycle Oven
hot air cycle drying oven,cycle oven,tray oven
RXH Series Hot Air Cycle Oven
hot air cycle drying oven,cycle oven,tray oven

RXH Series Hot Air Cycle Oven

Model NO.
RXH Series
Quantity:
The Hot Air Cycle Oven is widely used in pharmaceutical, chemical, food and other industries to heat and dry materials or dehumidify, heat and solidify, dry and dehydrate materials. Such as raw materials, Chinese medicine pieces, powders, granules, dehydrated vegetables and containers, etc. The Hot Air Cycle Oven uses steam or electric heater to heat the air to circulate and dry the material. The temperature difference in the box is small, and the drying is uniform. During the drying process, fresh air is continuously replenished and hot and humid air is exhausted to maintain proper humidity, so that the drying process is always in the best state.

Feature
1.Hot air circulates in the oven, with high thermal efficiency and energy saving.
2.Using forced ventilation, there is an air duct in the oven, and the material is evenly dried.
3.The drying tray can be perforated or non-perforated according to the material.
4.Mobile drying trolley for easy transfer and loading and unloading of materials.
5.The door lock is equipped with reinforcing ribs to avoid insufficient sealing after long-term use of the equipment.
6.Customizable two-way door, used in workroom with different clean room levels.



Technical parameters

ModelRXH-B-0RXH-B-IRXH-B-IIRXH-B-IIIRXH-B-IV
Dry amount each(kg)60120240360480
Matched power(kw)0.450.450.91.351.8
Steam expend(kg/h)620457090
Heat dispelling area(m²)5204080100
Air flow(m³/h)3450345069001035013800
Diff in up down temp℃±2±2±2±2±2
Drying tray244896144192
Overall dimensions(mm)1370*1200*22002300*1200*22002300*2210*22003300*2210*22004460*2210*2200
Weight(kg)8001500180022002800
Drying pushcart12468
