WF-B Series Dust Collecting Crushing Set

Model NO.
WF-B Series
Quantity:
The material enters the pulveriser cavity from the feeding hopper, and is thrown from the center to the crusher cavity wall by the centrifugal force generated by the high-speed rotation of the movable toothed plate. Finally, the fine particles are discharged from the bottom through the sieve plate, and the coarse powder is repeatedly pulverized in the machine. The pulveriser machine is suitable for pharmaceutical, chemical, food and other industries to crush dry brittle materials. The pulveriser machine is a crushing equipment that integrates crushing and vacuuming.

Function
1.Diversified crushing mechanisms: toothed disc type, turbine type, air-cooled type, blade type and hammer type, suitable for various materials.
2.The pulveriser machine can be equipped with a cyclone separator and a dust collector, and there is no dust flying during the production process, the fine powder retained by the dust collection bag can be effectively recovered, reducing the loss rate of materials.
3.The easy-to-remove screen can achieve different degrees of crushing thickness.
4.The shell of the pulveriser can be equipped with jacket cooling water, which is suitable for highly heat-sensitive materials.

Technical parameters

ModelWF-20BWF-30BWF-40BWF-60B
Production capacity (kg/h)60-150100-300160-800250-1200
Spindle speed (r/min)4500380034002800
Feed size (mm)≤6≤6≤6≤10
Crushing fineness (mesh)60-12060-12060-12060-120
Crushing motor (kw)45.5122
Dust collection motor (kw)0.750.751.53
Dimensions  (mm)1100*600*16501200*650*16501350*700*17001750*1100*1950
