YK Series Swing Type Granulator
YK Series Swing Type Granulator
Grinding machine,grinder machine price,granulating machine
YK Series Swing Type Granulator
Grinding machine,grinder machine price,granulating machine

YK Series Swing Type Granulator

Model NO.
YK Series
Quantity:

The granulating machine can make the mixed powder into granules, and can also pulverize the block dry material into the desired granules.This granulating machine is suitable for granulation of dry bulk raw materials in the pharmaceutical, chemical and food industries and other irregular granules produced by granulation to increase fluidity. This granulating machine also suitable for re-granulation of unsatisfactory tablets.Under the forward and reverse rotation of the rotating drum, the equipment is forced to pass through the screen to make particles.


Function

1.The material is extruded from the screen to make granules, and the produced granules are uniform and do not need to be screened.
2.The screen is easy to disassemble, and the screens of different meshes can be replaced at will to make particles of different thicknesses.
3.The main shaft of the granulating machine is above the gearbox, and a strict shaft head sealing structure is designed to ensure that the shaft does not leak oil, and does not penetrate the material, so as to avoid the material being polluted by lubricating oil.
4.By adjusting the tightness of the screen and the rotational speed of the drum, the particle size and density of the particles can be controlled to a certain extent.



Technical parameter

ModelCapacity(kg/h)Power(kw)Speed of cylinder(rpm)Swing angleDiameter of cylinder(mm)Overall Dimensios(mm)Weight(kg)
YK-10030-2001.265360°Φ100700*400*1050280
YK-160100-300355360°Φ1601000*800*1300380
YK-160B  100-3005.555360°Φ160100*800*1300450
